DESCRIPTION

Basic Info.

Max Feeding (mm)	100kg/H
Capacity(t/h)	Customized
Motor Power(kw)	0.75kw
Installation Slope	0
Overall Dimension	800mm*450mm*800mm
Screw Structure	Meshing/Non-Intermeshing
Speed Regulation	Frequency Control
Capacity	20-150 Kg/H
Hopper	80L
Certificate	CE TUV ISO Patent
Motor	Customized
Application	Granule, Short Filter and Powder
Screw Design	Twin-Screw
Transport Package	Wooden Case
Specification	100kg
Trademark	TENGDA
Origin	Nanjing, Jiangsu
HS Code	8428399000
Production Capacity	20sets/Week

Product Description

Automatic Side Screw Feeder Machine

Product model for your choosing:

TD-CW series building block forced side feeder parameter table
Type	L/D	Motor(kW)	Screw materiaI	BarreI cooIing	Dimension
					A(mm)	B(mm)	C(mm)	D(mm)	E(mm)	F(mm)	G(mm)	H(mm)	I(mm)	J(mm)	K(mm)
TD-CW-40	10	1.5	W6Mo5Cr4V2	Optional	96	70	30	0 37	365	90	126	1000	<D9	70	8
TD-CW-50	10	2.2	W6Mo5Cr4V2	Optional	96	85	38	48	365	100	130	1000	11	80	8
TD-CW-60	10	3	W6Mo5Cr4V2	Optional	126	85	46	4)58	415	130	160	1100	11	80	10
TD-CW-70	9	5.5	W6Mo5Cr4V2	Optional	146	90	53.5	4>68	430	135	165	1100	11	85	10

Product details:Our company's TD-CW forced side feeder series products are suitable for filling and reinforcing processes of engineering plastics and modified engineering plastics processing:it can feeds short fiber reinforced products (such as short glass fiber, short carbon fiber),mineral powder filling (such as Graphite, talcum powder, calcium carbonate, etc.) and inorganic mineral materials (such as flame retardants).
This machine uses the forced pushing force of the feeding screw to overcome the pressure in the extruder and force the filling into the extruder to effectively mix with the molten material in the extruder.
Machine features:

1. Feeding screw material: W6Mo5Cr4V2, modular design, the combination can be adjusted according to different materials.
2. The screw has a good pressure building effect and can effectively push the filler into the main extruder;
3. The screw and barrel are made of wear-resistant materials, with long service life;
4. There are drawers for collecting powder;which is easy for cleaning;
5. There are glass windows for easy observation of operating conditions;
6. Height fine-tuning mechanism, easy to connect and install with the main extruder;
7. Compact and stable structure, small footprint;

Advantages of extrusion production process with forced feeding system:

1. Protect the main extruder barrel, reduce friction, and prolong the service life of the main
2. Increase the amount of feed, thereby increasing the output;
3. Reduce the residence time of temperature-sensitive materials in the extruder
4. Closed feeding environment to reduce dust in the production environment;
5. Reduce the pre-mixing process of the mixer and reduce power consumption;
6. Reduce the load of mixing workers and saves labor.

Our certificates:Our company was awarded as Jiangsu High-tech Enterprise and National High-tech Enterprise.Won the title of"2021 Nanjing Gazelle Enterprise". This award represents the recognition by the Municipal Development and Reform Commission of Nanjing Tengda's prosperous and healthy development over the years and its achievements.Our company has passed ISO:9001 international quality management system certification,EU CE certification, TUV Rheinland certification, and has more than 30 patents.

Our customers:

Related products:https://chinatengda.en.made-in-china.com/product-list-1.html
FAQ:

Q: Are you trading company or manufacturer?
A: We are factory.We have the technical production team,and the workers are all very experienced
Q: Why choose you?
A:You can get a very fair price from us and our price can make you beat your competitors in the markeQ: What kind of certification do you have?
A: Our products have obtained ISO9001 and CE certification,the quality can be guaranteed.We focus onthe field of extrusion machine,and aim to be the best manufacturer of this field
Q:What's the payment?
A:L/C, T/T, Western Union, Paypal, Money Gram, Cash.
